GENERAL   EQUIPMENT   INC.

 Engine

 Make/Type:

International Engine South America,Intercooler,Turbodiesel,04cyl.

 Displacement:

2.8 L

 Bore & Stroke (mm):

93 x 102.5

 Compression Ratio:

9.7:1

 Maxim power (HP):

132

 R.P.M. at maxim power:

3.800

 Maxim torque:

36,2Kgf.m

 R.P.M. at maxim torque:

1.600

Transmission

Type:

5 Speed Manual

 No. of gears:

5 + 1 synchronized

 Ratio of gears:

4,473:1; 2,458:1; 1,472:1;  1,000:1; 0,809:1; R3,795:1

 Wheel Drive:

 Permanent 4x2 rear / Part time 4x4

w/manual locking hubs


 Transfer Box Type:

manual

 No. of gears:

2

 Normal ratio:

1.000

 Low ratio:

2

 Differential

Type:

Symmetric

 Drive ratio:

3.73

 Suspension

 Front axle:

Independent, coil springs, shocks

 Rear axle:

Rigid, leaf springs, shocks

 Steering

 Type:

Power Steering

 Brakes

 Type:

Dual system, power assisted

 Front:

Ventilated Discs

 Rear:

Drums

 Parking brake:

Mechanical/rear wheels

 Wheels

 Wheels:

16 x 7"

 Tires:

7.00 x 16

 Electrical

 Battery:

2 x 12v, 66Ah

 Alternator:

12v, 85A

 Dimensions

 Length (mm/in):

4530 (178)

 Width:

1835 (72)

 Height:

1875 (74)

 Wheel base:

2600 (102)

 Wheel track Ft.:

1475 (58)

 Wheel track Rr:

1475 (58)

 Minimum ground clearance:

190 (7)

 Weight

 Curb weight:

2.515kgs

 Performances

 Maxim speed:

99mph

Turning radius (m/ft):

12 / 36

 Slope:

40 Degrees

 Approach angle:

35 Degrees

 Departure angle:

27 Degrees
