GENERAL   EQUIPMENT   INC.

Siemens GAS Turbine: SGT600DLE, Year: 2011, hours: 553, Fuel: Dual(Natural Gas), power: 25mw, 10.5kv, 50hz

Siemens GAS Turbine

Model: SGT600DLE

Dual Shafts

Emission type: DLE(Dry Low Emission)

Made in Sewden

Year: 2011,

Power Turbine speed: 7759rpm

Equiv.Working hours: 553

Number of start：52times

Total Service time: 374

Equiv Operating Cycles: 58

Fuel:Dual(Natural Gas),

power: 25mw,

Voltage: 10.5kv

Frequnecy: 50hz(Gearbox Ratio:5.172,speed:7759rpm down to 1500rpm,alternator speed:1500rpm )

Quantity of Shafts: Dual Shafts(may drive for compressor)

scope of supply:

1-High Pressure Compressor,2-Combustor,3-High Pressure PT,4-PT,

5-GearBox(Voith)，6-Alternator(ABB),7-Gas control part,8-Control room,9-Recovery Heat Boiler

10-Original manual book,11-Chimney,12-Transformer,13-Dryer,15-Fans,16-Airconditionr,17-Control boxes

18-Control computer,19-Cable,20-Lube system

maintenance record:

a-The maintenance mainly involves passing hot air from the dryer to the combustion chamber. We have previously tried turning the dryer. Desiccant is placed inside the steam drum of the waste heat boiler.

b-The last run was in December 2017, and it was started every three months for about a year. Finally, we communicated with Siemens to adopt a long-term maintenance method, so we did not attempt to ignite again.
