MINELAYER





TYPE:

Vessel

DESCRIPTION:

Minelayer vessel

PRICE:

Upon Request

PACKING:

As is, Where is





minelayervessel



Subject unsold or market withdrawal





Exceptional deal ... In excellent fully working and top maintained condition.





Ex Minelayer Royal Swedish Navy, by. 1957, rebuilt 1987, major maintenance 2012, dim. 31.20 x 7.40 x 3.10m. 2 x Volvo diesel of 1987, bowthruster, gensets, pumps, sea cranes, 28 berths in several cabins, C.H. Airco. Compl. Stainless steel galley, cool storage etc. Unique sea going ship.




Vessel condition:

Excellent

Vessel type:

Ex Minelayer

Builder:

Shipyard Oskarshamn Sweden

Model:

Navy vessel

Class Notation:

No class at the ship

Guests:

28

Berths:

28

Cabins:

13

Heads:

28

No. Of engines:

2

Engine model:

Volvo TMDA 120

Engine hours:

6884

Fuel type:

Diesel

Drive type:

Shaft drive

Crusing Speed:

10 Knots

Maximum Speed:

12 Knots

Nominal length:

31.20m

Length over all:

31.20m

Beam:

7.40m

Maximum draft:

3.10m

Hull material:

Steel

Hull type:

Round Bottom

Hull colour:

Grey

Displacement:

245 metric tons

Fuel capacity:

12000 Litres

Water capacity:

20000 Litres





Engine(s)



Ship is hydraulically driven
Brand-type: 2 x Volvo TMDA 120
Built in: 1987
Running hours: 6.884 and 6.942 hours
HP: coming up
Cylinders: 6
Fuel: Diesel
Fuel tankage: 12.000 liters
Cooling: Outboard + closed on tank
Bow thruster: Hydraulic
Lubrication: Water
Speed: Cruise 10 knots/h - Full Speed 12 k/h
Compressor: For work air
Ship can sail separately on both engines.
Each main engine is equipped with a 70 KVA generator.
Both main engines are equipped with 4 hydraulic pumps.
2 for propulsion, 1 for the cranes and bow thruster
1 for power, many spare parts available.

Generator: Scania 70 KVA 400V + hydraulic






Accommodation



Navigation Equipment



VHF: 2 x hand GMDSS, 1 x Sailor RT5022 DSC
Compass: Liquid, electric + Giro compass
Radar: 2 x Decca day light Bridgemaster E
GPS: 2 x MX 412 Prof. DGPS Decca
Depth meter: Yes
Navtex: Yes
Auto Pilot: Robertson APG
Other: Navigation lights, log consilium
Rudder indicator, weather station
3 x centrifugal screen

Former Minelayer of the Royal Swedish Navy which was in use very recently by the Navy for hydrographic work. The ship has a complete stainless steel galley fully equipped to cook for 28 persons, above the galley is a cold storage with food elevator. Very complete ship: In each stay people can connect by phone, some of the neat cabins has a fridge, buro, airco and sink.
The engine room has a separate control room for the operator.
2 mess rooms and a large clear bridge fully navigational equipped, at each bridge wing outside is a steering position.
Very well maintained unique sea going vessel suitable for many purposes.





Equipment



Cranes: 2 x HIAB 110 Sea Crane max. 2000 KG
2 x hydraulic arm with hydraulic
Winches, 4 m. Over SP and P. 4 meters
Max. 1.500 KG, 2 m. Out board

Pumps: Large fire fighting/foam pump on
Front deck remote controlled
Several electric pumps



Electrics



Voltage: 24-220-400V + shore power
Batteries: start, light and safety batteries
Battery charger: 3 x 30 amp.
Dynamo: 2 x on main engines, 1 on generator



Safety Equipment



Fire extinguisher: Yes + fire-extinguishing system in ER Rescue buoys: Yes
Alarm system: Fire, bilge and engine alarm system



Certification



No certificates at the ship





Specification and photos are not contractual and are subject to verification upon inspection
