- Perimeter armoring of passenger compartment (roof and Vertical surfaces: glass, firewall, doors, pillars, quarter panels, ballistic overlaps, rear bulkhead, etc.) to provide protection against 7.62mm, 308 Winchester FMJ ammunition, in accordance with NIJ Standard 0108.01 Level 3 and/or CEN 1063 Level B6

- Floor of the vehicle is armored to withstand the blast and shrapnel from detonation of 2 x DM51 grenades exploded simultaneously.

- All window/door apertures shall be overlapped, with bullet catchers in the door window area.

- Vehicle Battery and Electronic Module protection

- Fuel tank protection

- Passenger door hinges mounting points shall be reinforced to prevent the door sagging and deformation of the door pillars.

- Door travel retainers.

- The materials used in the construction of the vehicle shall of the highest quality, and shall be tested in accordance with the ballistic protection levels specified.

- OEM style curved ballistic glass (wind screen, passenger doors), providing the level of protection as mentioned in Section 2 of the present quote

- Concealed ballistic flat glass modules installed in rear quarter panels and rear bulkhead, providing the level of protection B6

- Anti-spall layer on all glass

- No distortion, no delamination

- Original interior panels shall be modified as necessary, and reinstalled wherever design permits, to maintain vehicle’s original appearance

- Overlaps, windshield frame, rear bulkhead shall be re-upholstered using the highest quality materials and craftsmanship, matching OEM colors and quality as close as possible.

- OEM air conditioning and heater vents shall remain operable.

- Suspension reinforced as necessary to support the weight of the armor.

- Hutchinson runflat devices
