BUS ZGT6101DH 43+1+1 PAX
|
TYPE: |
Bus |
|
DESCRIPTION: |
Bus ZGT6101DH 43+1+1 Pax |
|
PRICE: |
Upon Request |
|
PACKING: |
Ex-Works |
BUS ZGT6101DH 43+1+1 PAX
ZGT6101DH
|
Dimension (L*W*H) |
10360mm*2500mm*3610mm |
|
|
Wheel Base |
5050 mm |
|
|
Top Speed |
±115 km/h |
|
|
Fuel Tank Capacity |
200 L |
|
|
Fuel Consumption |
±23L perl/100km |
|
|
Seat Capacity |
43+1+1 |
|
|
Engine |
||
|
Model |
YC6A240-20 (Euro II) |
|
|
Max. Power |
177 kw/2300rpm (240HP) |
|
|
Max. Torque |
890 N.m/1400-1600 rpm |
|
|
Displacement |
7.252L |
|
|
Chassis |
||
|
Clutch |
Single disk, dry, operated far hydraulically. |
|
|
Gearbox |
Manual, five gear-full synchromesh |
|
|
Rear Axle |
single-reduction, hypoid gear, ratio:4.5 |
|
|
Brake |
Pneumatic dual-circuit service brake, energy-accumulate spring parking brake |
|
|
Steering Gear |
Integral power steering system |
|
|
Tire |
9.00R20 |
|
|
Suspension |
Steel spring (optional NEWAY air suspension) |
|
|
ABS |
Optional |
|
|
Retarder |
Optional |
|
|
Body Equipment |
||
|
Audio Video |
Radio, (optional DVD, 17”LCD) |
|
|
Passenger Seat |
2+2 arrangement, Luxurious, high backrest, adjustable seat, adjusted transversely |
|
|
Passenger Door |
air pressure one front door, outward swung, mechanical door lock, (optional electrical control door lock) |
|
|
Luggage Compartment |
5m3 |
|
|
Rear View Mirror |
Manual rabbit ear shape (optional electrical mirror) |
|
|
Other Equipments |
1 unit vent, sun curtain, side window curtain, inner rear view mirror, luxury decoration, full glued window, return vehicle monitor, reading lamp, step lamp, |
|
|
Optional Equipments |
Digital clock, refrigerator, water counter |
|
|
Water heater system |
Optional 30000kcal/h |
|
|
Air conditioner |
24000kcal/h |
|
Specification and photos are not contractual and are subject to verification upon inspection
