47 M CASTOR



TYPE:

Boat

DESCRIPTION:

47 mtrs Ex-Mine Sweeper

PRICE:

Upon Request

PACKING:

As is, Where is





47 m ex-mine sweeper



Subject Unsold or Market Withdrawal









Fast Ex-Navy Mine-Sweeper 24kts, 4500HP



German Navy Fast Mine Sweeper. Abeking&Rasmussen "CASTOR"

POWER-BOAT! 4.500HP, up to 24kts!!! Perfect for use as a support/security-vessel. Good condition, extensive refit.

Easy-to-drive, just 3 people needed. Very manouvrous due to variable pitch props. Perfect base for support or patrol vessel as well as for dive-adventures!!! Long-Range.

We can train your crew and offer maintenance. We are ready to make any conversion you need for your mission.

We need to sell much below our own costs due to a new project.


TECHNICAL DATA OF THE CASTOR


NATO identification M 1051
Model: 340 fast minesweeper (Sagittarius class)
Launching July 12, 1962
Years of service December 11, 1962 until August 15, 1990


Material
Hull: 3 layers of mahogany!!!!!!
Deck: 20 mm iroko on teak stringer
Superstructure: 35 mm plywood with 3 mm GFK reinforcement
Measurement: Length 47 m / width 7.5 m / draft 2.2 m
Displacement: 280 t
Cruising Speed: 16 knots
Max Speed: 24 knots


Engine:2 x Mercedes Benz 4 cycle 16 cylinder diesel engines (2.250 hp each), running great and less fuel consumption: 150l/h at 12kts, 250l/h at 20kts!!!


Tank content: 32,000 l diesel fuel + 4.000l day-tank: 10,000 l fresh water


Crew a staff of about 30 during naval service, today at least 3


Demilitarized. Previously M 1051 with an anti-aircraft gun


Accommodation: Cabins with about 30 beds, galley


Condition Extensive refit of hull and superstructure (>15.000 manpower-hours!!) in 2004/2005/2009, interior partitioning in original condition.


3-Blade Variable Pitch Props makes this vessel very manoeuvrable and controllable at any speed.

The ship is fully maintained.

READY TO SHIP TO LYBIA, SOMALIA, DUBAI.......! We already have inquiries from Somalia, but it seems, these are pirates.....))))

Between 1999 and 2004 the vessel was registered as a supply-vessel under Sao-Tomé flag. At the moment the boat is classified as a private motoryacht.



We can support you and offer you real prices for the personal conversions and amendments according to your wishes.



Vessel type:

Minesweeper

Builder:

Abeking&Rasmussen

Make:

Abeking & Rasmussen

Model:

340

Year constructed:

1962

Berths:

30

No. Of engines:

2

Engine model:

Mercedes Benz 16cyl Turbo

Engine power:

4500 HP

Fuel type:

Diesel

Drive type:

Shaft drive

Length over all:

150'

Beam:

7m

Maximum draft:

2m

Hull material:

Wood

Hull type:

Yacht-Syle

Hull colour:

grey

Displacement:

280 tons

Fuel capacity:

32000 Litres

Water capacity:

10000 Litres

Holding tank capacity:

4000 Litres



Engine(s)



2xMercedes-Benz 16 Cyl. 2250HP turbo-powered! (Typ.-No: MB 638, MTU 652)
3 x 3 blade (pitch-variable) rudder-system. Overhauled in 2005, same turbo-charger. Two power-generators (Total 100kw) - one was completely overhauled last year - are running well.



Construction



It was built 1961 at the famous yacht yard "Abeking & Rasmussen", where a lot of excellent yachts have been built.

The ship was REFITED in 2005. The extensive refit of the CASTOR required almost a full year´s effort by both people and machinery (more than 15,000 hours). The prescribed program included maintenance of the engines and technical periphery, renovation of the deck and hull, and the entire overhaul of the underwater hull at the Turkish naval shipyard in Aksas. Old paint and fillings were removed from the entire outside wood up to the last corner, and the wood was professionally repaired, if necessary, the wood was then repainted in the old splendor, naval grey.

Last dry docking in April last year in turkey.


New underwater coating in April last year.

Easy to drive!!!


VISIONS
The very elegant hull lines have inspired the owners of CASTOR to contact various designers and to invite them to illustrate their vision of how they see the CASTOR in future. Those design studies show CASTOR unusual and highly interesting potential.
While the vessel is now for sale in her excellent state, the current owners are very keen on offering the boat itself but also a very interesting package including a great technical documentation.
Also they offer assistance to realise any proposed conversion.






47 MTRS FAST PATROL BOAT





This is an ex government patrol vessel built by the famous Burmeister Yard in Germany.

The vessel is exceptionally strong due to its massive multi-layered laminated wood structure.

It is an extremely seaworthy vessel due to its proven hull design and cruises at 16 knots and goes up to 18 knots.

Accommodations are for 38.

The vessel is perfect for use in a variety of different functions and could easily be converted to an expedition yacht (like its sistership).

The vessel is in very good condition and fully operational.

Specifications



No. Of engines:

2

Engine model:

MTU MD

Fuel type:

Diesel

Length over all:

152'


Engine(s)



Main engines: 2 x MTU MD 16V 538 TB90 diesels; 2 500 BHP each sustained

Shafts, CPP props, the engines, props and shafts are of non-magnetic materials.



Five diesel generators outputting DC and AC of various values

Shore power 220/110V

Speed,15 kts sustainable, 18 kts max.

Range 4000 NM at 12 knots.

Fuel consumption: 5.5 t/d at 12 knots.

Fuel tank capacity: 46 T + 20 T additional below Main deck.

Water tank capacity 20T

Water maker 4T per day

Construction



PARTICULARS:



Built: 1958, by Burmester in Bremen, Germany.

Flag: USA.

Safety certification by International Register of Shipping.

Dry docking: October 2010.

Tonnage (ITC69): 392 GRT, 117 NRT.

Dimensions

LOA  (47.1m)

Beam (8.3m)

Draft  (2.8m)


Structure: The hull is 4 layers of moulded laminated mahogany and oak of 100 mm thick; superstructure is double layered marine plywood with GRP skin




Accommodation



Accommodations for 38 persons in 10 cabins

Fully air conditioned.

Four bathrooms

Four toilets

Four showers



Equipment



Towing winch with hydraulic power pack.

3 deck cranes/davits 1.5T/1T/1T

Fast semi-rigid rescue boat/tender.

Sewage treatment plant for full compliment.

Full set of radio-navigation equipment on the bridge.

Retractable Sonar: Atlas Elektronik DSQS011

Large Teak deck areas on all levels





Specification and photos are not contractual and are subject to verification upon inspection
